| Nomor Bagian | TM050RDH03-00 |
| Merek | TIANMA |
| Ukuran | 5.0 |
| Aplikasi | Industrial Portable |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 7S2P |
| Antarmuka | Parallel |
| merek panel | TIANMA |
| model panel | TM050RDH03-00 0 Compatible |
| ukuran panel | 5.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 188PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 108(W)×64.8(H) mm |
| bukaan bezel | 111.1(W)×67.9(H) mm |
| ukuran garis besar | 120.7(W)×75.8(H) ×3.1(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) (TM) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 12 o'clock |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 50% NTSC |
| jenis lampu | 7S2P WLED , 20K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | TBD |
| aplikasi | Industrial Portable Navigation MID UMPC MP3 PMP |
| antarmuka sinyal | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
