| Nomor Bagian | TM045XDZP08 |
| Merek | Tianma |
| Ukuran | 4.5 |
| Aplikasi | MPH |
| Resolusi | 540×960 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | TIANMA |
| model panel | TM045XDZP08 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 4.5 inch |
| resolusi | 540(RGB)×960 , qHD |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 55.485×98.64 mm |
| garis besar | 60.71×109.1 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193170% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 10S1PWLEDWithout Driver |
| antarmuka sinyal | MIPI (2 data lanes), 25 pins |
| tegangan masukan | 1.8/2.8V (Typ.)(IOVCC/VDD) |
| aplikasi | MPH |
