| Nomor Bagian | TM041XDHC02 |
| Merek | TIANMA |
| Ukuran | 4.1 |
| Aplikasi | Industrial |
| Resolusi | 720×720 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | 3S4P |
| Antarmuka | |
| pabrikan | TIANMA |
| ukuran layar | 4.1 inch |
| nomor piksel | 720(RGB)×720 247PPI |
| area aktif (mm) | 73.98 × 73.98 (H×V) |
| area bezel (mm) | 74.78 × 74.78 (H×V) |
| pencahayaan | 300 (Typ.)(cd/m²) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 68% NTSC |
| massa | 27.5g (Typ.) |
| tingkat penyegaran | - |
| nama model | TM041XDHC02 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 77.98 × 82 (H×V×D) |
| perlakuan | Hard coating |
| rasio kontras | 1200 : 1 (Typ.) (TM) |
| mode kerja | SFT, Normally Black, Transmissive |
| tanggapan | 35 (Typ.)(Tr+Td) ms |
| lampu latar | 3S4P WLED , 30K hours , No Driver |
| digunakan untuk | Industrial |
| layar sentuh | In-Cell Touch |
| AMS410GC01-0 | Samsung | 4.1 | 480×800 |
| AMS410GJ02-0 | Samsung | 4.1 | 480×800 |
| COM41H4M31XLC | ORTUSTECH | 4.1 | 320×240 |
| LS041Y3LW01 | SHARP | 4.1 | 800×480 |
| LT041MDM6000 | TOSHIBA | 4.1 | 480×800 |
