| Nomor Bagian | TM040YDH51 |
| Merek | TIANMA |
| Ukuran | 4.0 |
| Aplikasi | Mobile Phone |
| Resolusi | 480×800 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 7S1P |
| Antarmuka | |
| pabrikan | TIANMA |
| nama model | TM040YDH51 |
| ukuran layar | 4.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 480(RGB)×800 (WVGA) 235PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 51.84 × 86.4 (H×V) |
| garis besar (mm) | 57.24 × 98.3 × 2.3 (H×V×D) |
| area bezel (mm) | 52.84 × 87.4 (H×V) |
| perlakuan | Clear |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 600 : 1 (Typ.) (TM) |
| sudut pandang | 70/70/70/60 (Typ.)(CR≥10) |
| tanggapan | 20 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 60% NTSC |
| lampu latar | 7S1P WLED , No Driver |
| massa | TBD |
| digunakan untuk | Mobile Phone |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
