| Nomor Bagian | TM035HDZP04 |
| Merek | TIANMA |
| Ukuran | 3.5 |
| Aplikasi | Automotive Display |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | TIANMA |
| ukuran panel | 3.5" |
| resolusi | 240(RGB)×320, QVGA, 114PPI |
| area tampilan | 53.28(W)×71.04(H) mm |
| kecerahan | - |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 262K |
| frekuensi | 60Hz |
| berat | - |
| model panel | TM035HDZP04 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 58.28(W)×74.04(H) mm |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | SFT, Normally Black, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 10K hours , Without Driver |
| layar sentuh | - |
| aplikasi | Automotive Display |
