| Nomor Bagian | TM035HDHP13 |
| Merek | TIANMA |
| Ukuran | 3.5 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | TIANMA |
| ukuran panel | 3.5" |
| resolusi | 240(RGB)×320, QVGA, 114PPI |
| area tampilan | 53.28(W)×71.04(H) mm |
| ukuran garis besar | 64(W)×85(H) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 262K 60% NTSC |
| berat | - |
| model panel | TM035HDHP13 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | SFT, Normally Black, Transmissive |
| waktu merespon | - |
| jenis lampu | WLED , 20K hours |
| aplikasi | Outdoor High Brightness Handheld & PDA |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03-36 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| TM035KDH08 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
