| Nomor Bagian | TM028HDZG59 |
| Merek | TIANMA |
| Ukuran | 2.8 |
| Aplikasi | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antarmuka | 16-bit |
| merek | TIANMA |
| ukuran diagonal | 2.8 inch |
| format piksel | 240(RGB)×320 [QVGA] 141PPI |
| daerah aktif | 43.2(H)×57.6(V) mm |
| pencahayaan | 300 cd/m² (Typ.) |
| arah pandangan | - |
| sudut pandang | 70/70/70/58 (Typ.)(CR≥10) |
| warna pendukung | 65K/262K 63% NTSC |
| berat | TBD |
| kecepatan bingkai | - |
| tipe antarmuka | 16-bit 8080 parallel , 37 pins FPC |
| Sumber Daya listrik | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM028HDZG59 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 50(H)×69.2(V) mm |
| rasio kontras | 400:1 (Typ.) (TM) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [1S4P] , W/O Driver |
| dirancang untuk | Mobile Phone |
| panel sentuh | Without |
