| Nomor Bagian | TM028HDHG30 |
| Merek | TIANMA |
| Ukuran | 2.8 |
| Aplikasi | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | TIANMA |
| model panel | TM028HDHG30 |
| ukuran panel | 2.8" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 240(RGB)×320, QVGA, 141PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 43.2(W)×57.6(H) mm |
| bukaan bezel | - |
| kecerahan | - |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | - |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 65% NTSC |
| jenis lampu | WLED |
| frekuensi | - |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Handheld & PDA |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| PJ028MA-01A | Innolux | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
