| Nomor Bagian | TM026HDH02 |
| Merek | TIANMA |
| Ukuran | 2.6 |
| Aplikasi | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antarmuka | |
| pabrikan | TIANMA |
| nama model | TM026HDH02 |
| ukuran layar | 2.6 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 240(RGB)×320 (QVGA) 156PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 38.88 × 51.84 (H×V) |
| garis besar (mm) | - |
| pencahayaan | 240 cd/m² (Typ.) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 70/70/70/60 (Typ.)(CR≥10) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 65K/262K 60% NTSC |
| lampu latar | WLED , No Driver |
| massa | TBD |
| digunakan untuk | Mobile Phone |
| tingkat penyegaran | - |
| layar sentuh | Without |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
| A026EAN01.0 | AUO | 2.6 | 800×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS260CM61 | Samsung | 2.6 | 240×320 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
