| Nomor Bagian | TL139GDXP01-00 |
| Merek | TIANMA |
| Ukuran | 13.9 |
| Aplikasi | Laptop |
| Resolusi | 3000×2000 |
| Komposisi | LTPS TFT-LCD, LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | TIANMA |
| model panel | TL139GDXP01-00 |
| ukuran panel | 13.9" |
| tipe panel | LTPS TFT-LCD, LCM |
| resolusi | 3000(RGB)×2000, 259PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 293.85(W)×195.9(H) mm |
| bukaan bezel | - |
| kecerahan | 420 cd/m² (Typ.) |
| rasio kontras | 1500:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | SFT, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | WLED |
| frekuensi | 60Hz |
| layar sentuh | - |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
