| Nomor Bagian | TL055BDXP03 |
| Merek | TIANMA |
| Ukuran | 5.5 |
| Aplikasi | Mobile Phone |
| Resolusi | 1440×2560 |
| Komposisi | LCM , LTPS TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 5S3P |
| Antarmuka | MIPI |
| pabrikan | TIANMA |
| ukuran layar | 5.5 inch |
| nomor piksel | 1440(RGB)×2560 (Quad-HD) 537PPI |
| area aktif (mm) | 68.04 × 120.96 (H×V) |
| pencahayaan | - |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 70% NTSC |
| massa | TBD |
| tingkat penyegaran | 70Hz |
| jenis sinyal | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| sumber tegangan | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| maks. peringkat | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| nama model | TL055BDXP03 |
| tipe layar | LCM , LTPS TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| tanggapan | 8 (Typ.)(Tr+Td) ms |
| mode kerja | SFT, Normally Black, Transmissive |
| lampu latar | 5S3P WLED |
| digunakan untuk | Mobile Phone |
| layar sentuh | Without |
