| Nomor Bagian | TD170WGCA1 |
| Merek | TPO |
| Ukuran | 17.0 |
| Aplikasi | DMPC |
| Resolusi | 1280×1024 |
| Komposisi | LCM |
| Kecerahan | 260 |
| CR | 450:1 |
| Warna | 16.2M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | Toppoly |
| model panel | TD170WGCA1 10 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 17.0 inch |
| resolusi | 1280(RGB)×1024 , SXGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 337.92×270.336 mm |
| garis besar | 358.5×296.5×17.5 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 260 cd/m² (Typ.) |
| rasio kontras | 450:1 (Typ.) |
| menampilkan warna | 16.2M (6-bit + FRC), CIE193172% |
| waktu merespon | 4/12 (Typ.)(Tr/Td) |
| sudut pandang | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 4 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| LM170E03-TLH1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ2 | LG Display | 17.0 | 1280×1024 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| M200O1-L05 | Innolux | 20.0 | 1600×900 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
