| Nomor Bagian | TCG085WVLCF-G00 |
| Merek | Kyocera |
| Ukuran | 8.5 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| pabrikan | Kyocera |
| nama model | TCG085WVLCF-G00 |
| ukuran layar | 8.5 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 109PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 184.8 × 110.88 (H×V) |
| garis besar (mm) | 210 × 134 × 11.1 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare |
| pencahayaan | 320 cd/m² (Typ.) |
| rasio kontras | 500 : 1 (Typ.) (TM) |
| sudut pandang | 60/60/60/45 (Typ.)(CR≥10) |
| tanggapan | 15/35 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K 49% NTSC |
| lampu latar | WLED , 50K hours , No Driver |
| massa | TBD |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | 4-wire Resistive Touch, G/G |
| jenis sinyal | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
