| Nomor Bagian | T550QVN07.C CELL |
| Merek | AUO |
| Ukuran | 55 |
| Aplikasi | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | V-by-One |
| merek panel | AUO |
| model panel | T550QVN07.C CELL |
| ukuran panel | 55" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 3840(RGB)×2160, UHD, 80PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 1209.6(W)×680.4(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 1219.6(W)×691.9(H) ×1.36(D) mm |
| permukaan | Antiglare (Haze 2%), Hard coating (2H) |
| kecerahan | 0 cd/m² |
| rasio kontras | 4000:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | AMVA3, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| keterusan | 5.1% (Typ.)(with Polarizer) |
| menampilkan warna | 1.07B 70% NTSC |
| jenis lampu | No B/L |
| frekuensi | 60Hz |
| layar sentuh | Without |
| ic pengemudi | COFBuilt-in 12 source chips |
| berat panel | 2.55Kgs (Typ.) |
| aplikasi | TV Sets |
| antarmuka sinyal | V-by-One 8 lane , 51 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
