| Nomor Bagian | T315XW02 VK |
| Merek | AUO |
| Ukuran | 31.5 |
| Aplikasi | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 540 |
| CR | 2500:1 |
| Warna | 1.07B |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | T315XW02 VK |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 31.5 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | AMVA, Normally Black, Transmissive |
| daerah aktif | 697.685×392.256 mm |
| garis besar | 741×435 mm |
| permukaan | Antiglare (Haze 11%), Hard coating (3H) |
| kecerahan | 540 cd/m² (Typ.) |
| rasio kontras | 2500:1 (Typ.) |
| menampilkan warna | 1.07B (10-bit), CIE193188% |
| waktu merespon | 6.5 (Typ.)(G to G) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 16 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (1 ch, 10-bit), 41 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | LCTV |
