| Nomor Bagian | STCG057QVLAM-G02-S |
| Merek | Kyocera |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek | Kyocera |
| model | STCG057QVLAM-G02-S |
| ukuran diagonal | 5.7 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 320(RGB)×240 [QVGA] 70PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 115.2(H)×86.4(V) mm |
| garis besar redup. | 144(H)×104.8(V) ×13.5(D) mm |
| daerah bezel | 118.4(H)×89.0(V) mm |
| perlakuan | Glare (Haze 0%) |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 10/25 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥5) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 60% NTSC |
| sumber cahaya | WLED , 40K hours , W/O Driver |
| berat | 158g (Typ.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | - |
| panel sentuh | Without |
| tipe antarmuka | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G057VTN01.1 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| MC57T04L | Other | 5.7 | 320×240 |
| PD057VT3 | E Ink | 5.7 | 640×480 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| TM057QDHG02 | Tianma | 5.7 | 640×480 |
