| Nomor Bagian | ST5461B03-5 |
| Merek | CSOT |
| Ukuran | 55 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | CSOT |
| ukuran diagonal | 55 inch |
| format piksel | 1920(RGB)×1080 [FHD] 40PPI |
| daerah aktif | 1209.6(H)×680.4(V) mm |
| daerah bezel | - |
| pencahayaan | 0 cd/m² |
| arah pandangan | Symmetry |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| ketebalan pelat | 0.50+0.50 mm |
| warna pendukung | 16.7M 72% NTSC |
| berat | 3.50Kgs (Max.) |
| kecepatan bingkai | 60Hz |
| detail d-ic | COF Built-in 6 source + 8 gate chips |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | ST5461B03-5 |
| jenis | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 1223.6(H)×697.1(V) ×1.35(D) mm |
| perlakuan | Antiglare (Haze 2%), Hard coating (3H) |
| rasio kontras | 4000:1 (Typ.) (TM) |
| waktu merespon | 7 (Typ.)(G to G) |
| Modus operasi | HVA, Normally Black, Transmissive |
| transmisi | 6.5% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| dirancang untuk | TV Sets |
| panel sentuh | Without |
