| Nomor Bagian | SG2701B01-4 |
| Merek | CSOT |
| Ukuran | 27.0 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| pabrikan | CSOT |
| nama model | SG2701B01-4 |
| ukuran layar | 27.0 inch |
| tipe layar | CELL, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1080 (FHD) 81PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 597.888 × 336.312 (H×V) |
| garis besar (mm) | 608.888 × 348.337 × 1.24 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare (Haze 25%) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 4000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 8 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | HVA, Normally Black, Transmissive |
| ketebalan kaca | 0.40+0.50 mm |
| keterusan | 4.6% (Typ.)(with Polarizer) |
| kedalaman warna | 16.7M 99% sRGB |
| lampu latar | No B/L |
| massa | - |
| digunakan untuk | Desktop Monitor |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| daftar ic driver | Built-in COF 6 source chips |
| jenis sinyal | LVDS (2 ch, 8-bit) , Connector 30 pins |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
