| Nomor Bagian | S029Q03 |
| Merek | CDTECH |
| Ukuran | 2.9 |
| Aplikasi | Stretched Bar LCD |
| Resolusi | 320×120 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | 8/9/16/18-bit |
| merek | CDTECH |
| model | S029Q03 |
| ukuran diagonal | 2.9 inch (1/2 cut of 3.5") |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 320(RGB)×120 115PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 70.08(H)×26.284(V) mm |
| garis besar redup. | 76.9(H)×37.72(V) ×3.46(D) mm |
| daerah bezel | 72.68(H)×28.88(V) mm |
| perlakuan | - |
| pencahayaan | 300 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) (TM) |
| arah pandangan | 12 o'clock |
| waktu merespon | 8/17 (Typ.)(Tr/Td) |
| sudut pandang | 65/65/55/65 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 61% NTSC |
| sumber cahaya | WLED [6S1P] , 30K hours , W/O Driver |
| berat | TBD |
| dirancang untuk | Stretched Bar LCD |
| kecepatan bingkai | - |
| panel sentuh | Without |
| tipe antarmuka | 8/9/16/18-bit 6800/8080 parallel, 6/9/16/18-bit RGB, SPI , 54 pins FPC |
| Sumber Daya listrik | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
