| Nomor Bagian | QT156WHM-N50 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop Printer Home |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | BOE |
| ukuran panel | 15.6" |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| area tampilan | 344.232(W)×193.536(H) mm |
| kecerahan | 200 cd/m² (Typ.) |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 45% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Wedge (PCBA Bent, T≥5.2mm) |
| antarmuka sinyal | LVDS (1 ch, 6-bit) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | QT156WHM-N50 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 500:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 12 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop Printer Home Appliance |
