| Nomor Bagian | PT320CT01-1 |
| Merek | HKC |
| Ukuran | 32.0 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | HKC |
| model | PT320CT01-1 |
| ukuran diagonal | 32.0 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 1920×1080(RGB) [FHD] 69PPI |
| konfigurasi | RGB Horizontal Stripe |
| daerah aktif | 698.4(H)×392.85(V) mm |
| garis besar redup. | 715(H)×411(V) ×1.39(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 3%), Hard coating (3H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 3000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 8.5 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | FSA, Normally Black, Transmissive |
| ketebalan pelat | 0.50+0.50 mm |
| transmisi | 5.5% (Typ.)(with Polarizer) |
| warna pendukung | 16.7M 69% NTSC |
| sumber cahaya | No B/L |
| berat | 924g (Typ.) |
| dirancang untuk | TV Sets |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| detail d-ic | COF Built-in 2 source chips |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
