| Nomor Bagian | NV166FHM-N41 |
| Merek | BOE |
| Ukuran | 16.6 |
| Aplikasi | Laptop Gaming |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | 11S6P |
| Antarmuka | eDP |
| merek panel | BOE |
| model panel | NV166FHM-N41 (BOE084F) |
| ukuran panel | 16.6" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 132PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 368.64(W)×207.36(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 375.14(W)×231.66(H) ×5.4(D) mm |
| permukaan | Antiglare |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 9 (Typ.)(Tr+Td); 3 (Typ.)(G to G) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | 11S6P WLED , 15K hours , With LED Driver |
| frekuensi | 144Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop Gaming |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
