| Nomor Bagian | NV156FHM-N47 |
| Merek | BOE |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 10S4P |
| Antarmuka | eDP |
| merek panel | BOE |
| ukuran panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| area tampilan | 344.16(W)×193.59(H) mm |
| ukuran garis besar | 350.76(W)×223.8(H) ×3.2(D) mm |
| kecerahan | 250 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 262K 45% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| antarmuka sinyal | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | NV156FHM-N47 (BOE06D2) 9 Compatible |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | 10S4P WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| B156XW03 V2 | AUO | 15.6 | 1366×768 |
| LP156WHU-TPB1 | LG Display | 15.6 | 1366×768 |
| LP156WHU-TPE1 | LG Display | 15.6 | 1366×768 |
| LTN156AT05-601 | Samsung | 15.6 | 1366×768 |
| LTN156AT06-001 | Samsung | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
