| Nomor Bagian | NV116WHM-T04 |
| Merek | BOE |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antarmuka | eDP |
| merek panel | BOE |
| model panel | NV116WHM-T04 (BOE0965) |
| ukuran panel | 11.6" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 256.125(W)×144(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 278(W)×168(H) ×3.2(D) mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 50% NTSC |
| jenis lampu | 8S3P WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | On-Cell Touch |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
