| Nomor Bagian | NV116WHM-A23 |
| Merek | BOE |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , Assem |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 6S4P |
| Antarmuka | |
| merek panel | BOE |
| ukuran panel | 11.6" |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| area tampilan | 256.125(W)×144(H) mm |
| ukuran garis besar | 287.7(W)×185.6(H) ×4.05(D) mm |
| kecerahan | 200 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 262K 50% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| model panel | NV116WHM-A23 (BOE0744) |
| tipe panel | a-Si TFT-LCD , Assembly |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Anti-Scatter, Hard coating (7H) |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | - |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | 6S4P WLED , 15K hours , With LED Driver |
| layar sentuh | PCAP, Optical Bonding |
| aplikasi | Laptop |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
