| Nomor Bagian | NV101WXM-N51 |
| Merek | BOE |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | BOE |
| ukuran panel | 10.1" |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| area tampilan | 216.96(W)×135.6(H) mm |
| ukuran garis besar | 228.21(W)×148.86(H) ×4.59(D) mm |
| kecerahan | 250 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 50% NTSC |
| frekuensi | 60Hz |
| berat | 145g (Max.) |
| model panel | NV101WXM-N51 (BOE070B) |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Glare (Haze 0%), Hard coating (2H), Antireflection |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , With LED Driver |
| layar sentuh | Without |
| aplikasi | Pad & Tablet |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101ND07CW | CPT | 10.1 | 1024×600 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| DLC1010CIG-6 | Other | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101NWT2 R1 | IVO | 10.1 | 1024×600 |
