| Nomor Bagian | NT116WHM-A20 |
| Merek | BOE |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 8S4P |
| Antarmuka | |
| merek panel | BOE |
| ukuran panel | 11.6" |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| area tampilan | 256.125(W)×144(H) mm |
| ukuran garis besar | 278(W)×171.55(H) ×4.9(D) mm |
| kecerahan | 200 cd/m² (Typ.) |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 48% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Flat (PCBA Flat, T3.4~4.0mm) |
| model panel | NT116WHM-A20 (BOE063F) |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Hard coating (7H) |
| rasio kontras | 500:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 12 (Typ.)(Tr+Td) |
| jenis lampu | 8S4P WLED , 15K hours , With LED Driver |
| layar sentuh | PCAP, Optical Bonding |
| aplikasi | Laptop |
