| Nomor Bagian | NL8048BC21-03F |
| Merek | NLT |
| Ukuran | 8.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | NLT |
| ukuran diagonal | 8.0 inch |
| format piksel | 800(RGB)×480 [WVGA] 116PPI |
| daerah aktif | 174(H)×104.4(V) mm |
| daerah bezel | - |
| pencahayaan | 1000 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| warna pendukung | 262K/16.7M 72% NTSC |
| berat | 225g |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| model | NL8048BC21-03F |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 192(H)×122(V) mm |
| perlakuan | Antiglare |
| rasio kontras | 1000:1 (Typ.) (TM) |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| Modus operasi | SFT, Normally Black, Transmissive |
| sumber cahaya | WLED |
| dirancang untuk | Industrial Outdoor High Brightness |
| panel sentuh | Without |
