| Nomor Bagian | NL3224AC35-09 |
| Merek | NEC |
| Ukuran | 5.5 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | - |
| Antarmuka | |
| merek panel | NEC |
| ukuran panel | 5.5" |
| resolusi | 320(RGB)×240, QVGA, 72PPI |
| area tampilan | 111.36(W)×83.52(H) mm |
| kecerahan | - |
| sudut pandang | - |
| tampilan terbaik di | - |
| menampilkan warna | 262K |
| frekuensi | 60Hz |
| berat | - |
| model panel | NL3224AC35-09 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 400:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 5/25 (Typ.)(Tr/Td) |
| jenis lampu | |
| layar sentuh | Without |
| aplikasi | Industrial |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-05 | NLT | 5.5 | 320×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
