| Nomor Bagian | NL256204AM15-02A |
| Merek | NLT |
| Ukuran | 20.1 |
| Aplikasi | DMPC |
| Resolusi | 2560×2048 |
| Komposisi | LCM |
| Kecerahan | 850 |
| CR | 600:1 |
| Warna | Grayscale |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | NEC |
| model panel | NL256204AM15-02A |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 20.1 inch |
| resolusi | 2560(LCR)×2048 , QSXGA |
| mode tampilan | SA-SFT, Normally Black, Transmissive |
| daerah aktif | 399.36×319.49 mm |
| garis besar | 423.4×343.5×45.5 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 850 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) |
| menampilkan warna | Grayscale (8-bit) |
| waktu merespon | 15/15 (Typ.)(Tr/Td) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 12 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (4 ch, 8-bit) |
| tegangan masukan | 12.0V (Typ.) |
| roh: | |
| aplikasi | DMPC |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM201W01-STB1 | LG Display | 20.1 | 1680×1050 |
| LM201WE2-SLA1 | LG Display | 20.1 | 1680×1050 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| LQ201U1LW32 | SHARP | 20.1 | 1600×1200 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM300WQ5-SLA1 | LG Display | 30.0 | 2560×1600 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270MWN1 R0 | IVO | 27.0 | 1920×1080 |
