| Nomor Bagian | NL192120AC25-02 |
| Merek | NLT |
| Ukuran | 22.5 |
| Aplikasi | DMPC |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 420 |
| CR | 800:1 |
| Warna | 1.07B |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | NEC |
| model panel | NL192120AC25-02 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 22.5 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mode tampilan | UA-SFT, Normally Black, Transmissive |
| daerah aktif | 483.84×302.4 mm |
| garis besar | 542×362 mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 420 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 1.07B (10-bit), Adobe97% |
| waktu merespon | 6/6 (Typ.)(Tr/Td) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 120Hz |
| jenis lampu | 12 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (4 ch, 10-bit), 104 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | DMPC |
