| Nomor Bagian | NL192108AC10-01D |
| Merek | NLT |
| Ukuran | 9.0 |
| Aplikasi | IA |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | NLT |
| model panel | NL192108AC10-01D |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 9.0 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | UA-SFT, Normally Black, Transmissive |
| daerah aktif | 198.72×111.78 mm |
| garis besar | 214.6×130×9.6 mm |
| permukaan | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) |
| menampilkan warna | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| waktu merespon | 13/12 (Typ.)(Tr/Td) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (2 ch, 6/8-bit), 50 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
