| Nomor Bagian | NL13676BC25-07F |
| Merek | NLT |
| Ukuran | 15.6 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | 6 |
| Antarmuka | LVDS |
| merek panel | NLT |
| ukuran panel | 15.6" |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| area tampilan | 344.232(W)×193.536(H) mm |
| ukuran garis besar | 363.8(W)×215.9(H) ×13.15(D) mm |
| kecerahan | 1250 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K/16.7M 60% NTSC |
| frekuensi | 60Hz |
| berat panel | 1.07/1.17Kgs (Typ./Max.) |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | NL13676BC25-07F |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 347.55(W)×196.85(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| rasio kontras | 900:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 3/15 (Typ.)(Tr/Td) |
| jenis lampu | 6 strings WLED , 7K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Industrial Outdoor High Brightness |
