| Nomor Bagian | NL12880BC20-25F |
| Merek | NLT |
| Ukuran | 12.1 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1280×800 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3 |
| Antarmuka | LVDS |
| pabrikan | NLT |
| nama model | NL12880BC20-25F |
| ukuran layar | 12.1 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1280(RGB)×800 (WXGA) 124PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 261.12 × 163.2 (H×V) |
| garis besar (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| area bezel (mm) | 266.1 × 168.2 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 1600 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tanggapan | 15 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | 6 o'clock |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K/16.7M 50% NTSC |
| lampu latar | 3 strings WLED , 60K hours , No Driver |
| massa | 470g (Typ.) |
| digunakan untuk | Industrial Outdoor High Brightness |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
