| Nomor Bagian | NE135FBM-N41 |
| Merek | BOE |
| Ukuran | 13.5 |
| Aplikasi | Laptop |
| Resolusi | 2256×1504 |
| Komposisi | Oxide TFT-LCD, LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | 9S6P |
| Antarmuka | eDP |
| merek panel | BOE |
| model panel | NE135FBM-N41 (BOE08BC BOE095F) |
| ukuran panel | 13.5" |
| tipe panel | Oxide TFT-LCD, LCM |
| resolusi | 2256(RGB)×1504, 201PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 284.933(W)×189.955(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 289.993(W)×212.28(H) ×2.1(D) mm |
| permukaan | Hard coating (2H) |
| kecerahan | 415 cd/m² (Typ.) |
| rasio kontras | 1500:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | FFS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 100% sRGB |
| jenis lampu | 9S6P WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
