| Nomor Bagian | NE070NB-04F |
| Merek | Chimei Innolux |
| Ukuran | 7.0 |
| Aplikasi | Digital Photo Frame |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | No |
| Antarmuka | Parallel |
| merek | Chimei Innolux |
| model | NE070NB-04F |
| ukuran diagonal | 7.0 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 800(RGB)×480 [WVGA] 134PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 154.08(H)×85.92(V) mm |
| garis besar redup. | 162.5(H)×96.62(V) ×1.43(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare |
| pencahayaan | 0 cd/m² |
| rasio kontras | 500:1 (Typ.) (TM) |
| arah pandangan | 6 o'clock |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| ketebalan pelat | 0.50+0.50 mm |
| transmisi | 4.86% (Typ.)(with Polarizer) |
| warna pendukung | 262K/16.7M |
| sumber cahaya | No B/L |
| berat | 45.0g (Typ.) |
| dirancang untuk | Digital Photo Frame Portable DVD Player |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| detail d-ic | COG Built-in 1 source + 1 gate chips |
| tipe antarmuka | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| Sumber Daya listrik | 3.3/10.4/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
