| Nomor Bagian | N116BCA-EA1 |
| Merek | Innolux |
| Ukuran | 11.6 |
| Aplikasi | Laptop Industrial |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | 10S2P |
| Antarmuka | eDP |
| merek panel | Innolux |
| ukuran panel | 11.6" |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| area tampilan | 256.125(W)×144(H) mm |
| ukuran garis besar | 278(W)×168(H) ×3(D) mm |
| kecerahan | 250 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 262K 45% NTSC |
| frekuensi | 60Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| antarmuka sinyal | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | N116BCA-EA1 (CMN1138) |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare, Hard coating (3H) |
| rasio kontras | 800:1 (Typ.) (TM) |
| mode tampilan | AAS, Normally Black, Transmissive |
| waktu merespon | 14/11 (Typ.)(Tr/Td) |
| jenis lampu | 10S2P WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop Industrial |
