| Nomor Bagian | MV238QHB-N10 |
| Merek | BOE |
| Ukuran | 23.8 |
| Aplikasi | Desktop Monitor |
| Resolusi | 2560×1440 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | MV238QHB-N10 |
| ukuran panel | 23.8" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 2560(RGB)×1440, Quad-HD, 123PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 526.848(W)×296.352(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 534.84(W)×308.16(H) ×1.32(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 14 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| keterusan | - |
| menampilkan warna | 16.7M 100% sRGB |
| jenis lampu | No B/L |
| frekuensi | 60Hz |
| layar sentuh | Without |
| ic pengemudi | COF Built-in 8 source chips |
| berat panel | TBD |
| aplikasi | Desktop Monitor |
| antarmuka sinyal | LVDS (4 ch, 8-bit) , 70 pins Connector |
| tegangan masukan | 5.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
