| Nomor Bagian | MND307DA1-8 |
| Merek | CSOT |
| Ukuran | 13.3 |
| Aplikasi | Laptop |
| Resolusi | 2560×1600 |
| Komposisi | LTPS TFT-LCD , LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | CSOT |
| ukuran panel | 13.3" |
| resolusi | 2560(RGB)×1600, WQXGA, 227PPI |
| area tampilan | 286.08(W)×178.8(H) mm |
| ukuran garis besar | 291.08(W)×195.3(H) ×2.4(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 99% sRGB |
| frekuensi | 60Hz |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| antarmuka sinyal | eDP (4 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | MND307DA1-8 |
| tipe panel | LTPS TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 1500:1 (Typ.) (TM) |
| mode tampilan | FFS, Normally Black, Transmissive |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 15K hours , With LED Driver |
| layar sentuh | Without |
| aplikasi | Laptop |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133XW04 V0 | AUO | 13.3 | 1366×768 |
| G133I1-L01 | Innolux | 13.3 | 1280×800 |
| HV133WX1-100 | HYDIS | 13.3 | 1280×800 |
| LP133WH1-TLB1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLN4 | LG Display | 13.3 | 1366×768 |
| LP133X7-F2IB | LG Display | 13.3 | 1024×768 |
| LT133X8-122 | Samsung | 13.3 | 1024×768 |
| LTN133AT01-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
