| Nomor Bagian | MLAF061WE51 X |
| Merek | Mantix |
| Ukuran | 6.1 |
| Aplikasi | Mobile Phone |
| Resolusi | 720×1560 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | Mantix |
| model panel | MLAF061WE51 X |
| ukuran panel | 6.1" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 720(RGB)×1560, 282PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 64.8(W)×140.4(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 66.6(W)×145.3(H) ×0.3(D) mm |
| permukaan | Without Polarizer |
| kecerahan | 0 cd/m² |
| rasio kontras | 1500:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | FFS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| kedalaman kaca | 0.15+0.15 mm |
| keterusan | 3.9% (Typ.)(with Polarizer) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | No B/L |
| frekuensi | - |
| layar sentuh | In-Cell Touch |
| ic pengemudi | COGSuggest ICNL9911, FT8006P, ILI9881H, ICNL9911S, NT36525B, HX83102-D |
| berat panel | - |
| aplikasi | Mobile Phone |
| tegangan masukan | 1.8/5.5/-5.5V (Typ.)(IOICC/VSP/VSN) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
