| Nomor Bagian | MG1561B01-2 |
| Merek | CSOT |
| Ukuran | 15.6 |
| Aplikasi | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | CSOT |
| nama model | MG1561B01-2 |
| ukuran layar | 15.6 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1080 (FHD) 141PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 344.16 × 193.59 (H×V) |
| garis besar (mm) | 351.86 × 206.332 × 6.31 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
| pencahayaan | 250 cd/m² (Typ.) |
| rasio kontras | 3000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | VA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | WLED , 15K hours , With LED Driver |
| massa | 530g (Typ.) |
| digunakan untuk | Digital Signage |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (2 ch, 8-bit) , Connector 40 pins |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
