| Nomor Bagian | MCT-G320240DTCW-151N |
| Merek | TRULY |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | CSTN-LCD , LCM |
| Kecerahan | |
| CR | 45:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antarmuka | Parallel |
| merek | TRULY |
| ukuran diagonal | 5.7 inch |
| format piksel | 320(RGB)×240 [QVGA] 70PPI |
| daerah aktif | 115.18(H)×86.38(V) mm |
| daerah bezel | 119.18(H)×90.38(V) mm |
| pencahayaan | 220 cd/m² (Typ.) |
| arah pandangan | - |
| sudut pandang | 50/50/55/40 (Typ.)(CR≥10) |
| warna pendukung | Color |
| berat | - |
| kecepatan bingkai | - |
| tipe antarmuka | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| model | MCT-G320240DTCW-151N |
| jenis | CSTN-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 158.5(H)×109(V) ×9.2(D) mm |
| perlakuan | - |
| rasio kontras | 45:1 (Typ.) (TM) |
| waktu merespon | 215/110 (Typ.)(Tr/Td) |
| Modus operasi | STN, Normally Black, Transmissive |
| sumber cahaya | CCFL [1 pcs] , 15K hours , W/O Driver |
| dirancang untuk | Industrial |
| panel sentuh | Without |
