| Nomor Bagian | M102AWF2 R3 |
| Merek | IVO |
| Ukuran | 10.3 |
| Aplikasi | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | IVO |
| model | M102AWF2 R3 |
| ukuran diagonal | 10.3 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×720 200PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 243.65(H)×91.37(V) mm |
| garis besar redup. | 261.14(H)×109.3(V) ×15.8(D) mm |
| daerah bezel | 245.65(H)×94.37(V) mm |
| perlakuan | Hard coating (3H) |
| pencahayaan | 800 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 75% NTSC |
| sumber cahaya | WLED [8S3P] , 10K hours , W/O Driver |
| berat | 350g (Max.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 55Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 50 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
