| Nomor Bagian | M101GWWF R0 |
| Merek | IVO |
| Ukuran | 10.1 |
| Aplikasi | Laptop |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | IVO |
| model | M101GWWF R0 |
| ukuran diagonal | 10.1 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 216.96(H)×135.6(V) mm |
| garis besar redup. | 229.46(H)×149.1(V) ×4.56(D) mm |
| daerah bezel | - |
| perlakuan | Glare (Haze 0%), Hard coating (3H) |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M |
| sumber cahaya | WLED , 25K hours , With LED Driver |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| dirancang untuk | Laptop |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
