| Nomor Bagian | M101GWWC R5 |
| Merek | IVO |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 7S4P |
| Antarmuka | |
| pabrikan | IVO |
| nama model | M101GWWC R5 |
| ukuran layar | 10.1 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×1280 (WXGA) 150PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 135.36 × 216.58 (H×V) |
| garis besar (mm) | 142 × 228.5 × 4.5 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 60% NTSC |
| lampu latar | 7S4P WLED , 22K hours , No Driver |
| massa | 145g (Max.) |
| digunakan untuk | Pad & Tablet |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
