| Nomor Bagian | M101GW4G R0 |
| Merek | IVO |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 5S4P |
| Antarmuka | MIPI |
| merek panel | IVO |
| ukuran panel | 10.1" |
| resolusi | 1200(RGB)×1920, WUXGA, 225PPI |
| area tampilan | 135.36(W)×216.576(H) mm |
| ukuran garis besar | 147.78(W)×232(H) ×4.8(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 67% NTSC |
| frekuensi | 60Hz |
| berat panel | 155g (Max.) |
| antarmuka sinyal | MIPI (4 data lanes) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | M101GW4G R0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | 5S4P WLED , 22K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Pad & Tablet |
