| Nomor Bagian | M090AWP4 R1 |
| Merek | IVO |
| Ukuran | 9.0 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| pabrikan | IVO |
| ukuran layar | 9.0 inch |
| nomor piksel | 800(RGB)×480 (WVGA) 104PPI |
| area aktif (mm) | 198 × 112.08 (H×V) |
| area bezel (mm) | 200.2 × 114.28 (H×V) |
| pencahayaan | 750 cd/m² (Typ.) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| pemandangan bagus di | 6 o'clock |
| kedalaman warna | 262K 70% NTSC |
| massa | - |
| tingkat penyegaran | 60Hz |
| jenis sinyal | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| maks. peringkat | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| nama model | M090AWP4 R1 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 700 : 1 (Typ.) (TM) |
| tanggapan | 12 (Typ.)(Tr+Td) ms |
| mode kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , No Driver |
| digunakan untuk | Outdoor High Brightness Automotive Display |
| layar sentuh | Without |
