| Nomor Bagian | M070AWPA R0 |
| Merek | IVO |
| Ukuran | 7.0 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel |
| merek | IVO |
| model | M070AWPA R0 |
| ukuran diagonal | 7.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 133PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 152.4(H)×91.4(V) mm |
| garis besar redup. | 166(H)×105.8(V) ×10.5(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 1000 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | WLED [6S3P] , 30K hours , W/O Driver |
| berat | 187/206g (Typ./Max.) |
| dirancang untuk | Outdoor High Brightness Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | Parallel RGB (1 ch, 8-bit) , 50 pins FPC |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LD070WS2-SL03 | LG Display | 7.0 | 1024×600 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
