| Nomor Bagian | LTN154BT05-D01 |
| Merek | Samsung |
| Ukuran | 15.4 |
| Aplikasi | NBPC |
| Resolusi | 1440×900 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | SAMSUNG |
| model panel | LTN154BT05-D01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.4 inch |
| resolusi | 1440(RGB)×900 , WXGA+ |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 331.56×207.225 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | |
| kecerahan | |
| rasio kontras | |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | |
| sudut pandang | |
| frekuensi | 60Hz |
| jenis lampu | 1 pcsCCFL |
| antarmuka sinyal | LVDS (2 ch, 6-bit) |
| aplikasi | NBPC |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| CLAA154WB05AN | CPT | 15.4 | 1280×800 |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP154WU1-A1K1 | LG Display | 15.4 | 1920×1200 |
| LP154WX4-TLCB | LG Display | 15.4 | 1280×800 |
| LTN154BT02-004 | Samsung | 15.4 | 1440×900 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN154BT05-D01 | Samsung | 15.4 | 1440×900 |
| LTN154BT07-S01 | Samsung | 15.4 | 1440×900 |
| CLAA133WB01A | CPT | 13.3 | 1366×768 |
| LP133WP1-TJAA | LG Display | 13.3 | 1440×900 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LTM10C349 | TOSHIBA | 10.4 | 800×600 |
| LTN121AT02-A01 | Samsung | 12.1 | 1280×800 |
| LTN133AT15-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| LTN150XG-L02 | Samsung | 15.0 | 1024×768 |
| LTN156AT05-S01 | Samsung | 15.6 | 1366×768 |
| QD15TL04 Rev.04 | QDI | 15.4 | 1280×800 |
