| Nomor Bagian | LTN133YL06-H01 |
| Merek | SAMSUNG |
| Ukuran | 13.3 |
| Aplikasi | Laptop |
| Resolusi | 3200×1800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | 9S6P |
| Antarmuka | eDP |
| merek panel | SAMSUNG |
| model panel | LTN133YL06-H01 (SDC415A) |
| ukuran panel | 13.3" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 3200(RG/BW)×1800, Quad-HD+, 226PPI |
| format piksel | RG/BW LCD PenTile |
| area tampilan | 293.44(W)×165.06(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 306.15(W)×194.31(H) ×2.8(D) mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | PLS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 72% NTSC |
| jenis lampu | 9S6P WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
